         THE WINDOWS AND DOORS:

Window series PRIMAVERA
Exterior window executable in various essences, thickness of fixed frame: 68x79 mm. Thickness of the opening wing: 68x78; with drip of wood; double glazing 4+18+4 B.E.+ GAS (U=1,1) on the windows and 3+3+15+3+3 B.E.+ GAS (U=1,1) on the French doors. With siliconisation to view on the outside of the double glazing frame; glazing bead on one side; Joint cover frames veneered mm. 70X10 on the inside and of massive wood mm. 30X10 on the outside; complete with  ironmongery for tilt and wing opening and N. 01  against burglary spot (brand MAICO); complete with triple seal of urethane foam, color: gray or light brown; handle of chromed aluminum; window colored with walnut impregnating and water-based paint.
data sheet

In the windows there is the possibility to modify or add a variety of options:
-double glazing with different values ​of thermal and acoustic  transmittance;
-ironmongery with higher level of security;
-handles
-insertion of mosquito screen and blind
-various finishes, according to the essences and the types
Here you can see the detail of the subframe.

Window series INVERNO
Exterior window executable in various essences, thickness of fixed frame: 68x79 mm. Thickness of the opening wing: 68x76 as regards the part in wood, in addition the aluminum part for a total window frame of about 85 mm.; complete with single glazing and possibility of double glazing; complete with double urethane foam seal in the wing and a rubber gasket of black color in the frame; joint cover frames veneered mm. 70X10 only on the inside; with ironmongery for tilt and wing opening and N. 04 against burglary spot. The French doors are equipped with aluminum lower threshold. Window with outer side of aluminum, with RAL color at choise or decorated in the same color, complete with triple seal black rubber.
Data sheet
